Product Details
Place of Origin: China
Brand Name: E-link
Certification: RoHS,CE
Model Number: LNK-SFP50G-LR
Payment & Shipping Terms
Minimum Order Quantity: 1pcs
Price: To be negotiated
Packaging Details: SFP Fiber Transceivers
Delivery Time: 5-15working days
Payment Terms: L/C,, T/T, Western Union, MoneyGram,Credit Card
Supply Ability: 500PCS/Month
Keyword: |
SFP Fiber Transceivers |
Form Factor: |
QSFP28 |
Max Data Rate: |
53.125Gbps |
Connector: |
Duplex LC |
Wavelength: |
1310nm |
Max Cable Distance: |
10km |
Keyword: |
SFP Fiber Transceivers |
Form Factor: |
QSFP28 |
Max Data Rate: |
53.125Gbps |
Connector: |
Duplex LC |
Wavelength: |
1310nm |
Max Cable Distance: |
10km |
SFP Fiber Transceivers Generic Compatible 50GBASE-LR QSFP28 10km Duplex LC SMF
SFP Fiber Transceivers Overview
Generic Compatible 50GBASE QSFP28 transceiver supports up to 10km link lengths over OS2 SMF via a LC duplex connector. The built-in digital diagnostics monitoring (DDM) allows access to real-time operating parameters via the I2C interface. This transceiver is suitable for 50GBASE Ethernet, 5G Network Mid/Backhaul applications.
SFP Fiber Transceivers Advantages
SFP Fiber Transceivers Technical Description
Form Factor
QSFP28
Max Data Rate
53.125Gbps
Wavelength
1310nm
Max Cable Distance
10km
Connector
Duplex LC
Media
SMF
Transmitter Type
DFB
Receiver Type
APD
TX Power
-4.5~4.2dBm
Receiver Sensitivity
<-10.8dBm
Powerbudget
6.3dB
Receiver Overload
5.2dBm
Power Consumption
<3.5W
Extinction Ratio
3.5dB
DDM/DOM
Supported
Commercial Temperature Range
0 to 70°C (32 to 158°F)
