Product Details
Place of Origin: China
Brand Name: E-link
Certification: RoHS,CE
Model Number: LNK-QSFP28-IR4
Payment & Shipping Terms
Minimum Order Quantity: 1pcs
Price: To be negotiated
Packaging Details: SFP Fiber Transceivers
Delivery Time: 5-15working days
Payment Terms: L/C,, T/T, Western Union, MoneyGram,Credit Card
Supply Ability: 500PCS/Month
Keyword: |
SFP Fiber Transceivers |
Form Factor: |
QSFP28 |
Max Data Rate: |
103.125Gbps |
Connector: |
Duplex LC |
Wavelength: |
1271nm, 1291nm, 1311nm And 1331nm |
Max Cable Distance: |
2km |
Keyword: |
SFP Fiber Transceivers |
Form Factor: |
QSFP28 |
Max Data Rate: |
103.125Gbps |
Connector: |
Duplex LC |
Wavelength: |
1271nm, 1291nm, 1311nm And 1331nm |
Max Cable Distance: |
2km |
SFP Fiber Transceivers 100GBASE-CWDM4 QSFP28 2km DOM Duplex LC SMF
LNK-QSFP28-IR4 is designed for use in 100GBASE Ethernet throughput up to 2km over single mode fiber (SMF). The 100 Gigabit Ethernet signal is carried over four wavelengths at 1271, 1291, 1311, 1331 nm.It is suitable to be used in various applications, such as data centers, high-performance computing networks,enterprise core and distribution layer applications.
SFP Fiber Transceivers Advantages
SFP Fiber Transceivers Technical Description
Form Factor
QSFP28
Max Data Rate
103.125Gbps
Wavelength
1271nm,1291nm,1311nm and 1331nm
Max Cable Distance
2km
Connector
Duplex LC
Media
SMF
Transmitter Type
4 x CWDM DML (DFB)
Receiver Type
PIN
TX Power
-6.5~2.5dBm
Receiver Sensitivity
<-11.5dBm
Powerbudget
5dB
Receiver Overload
2.5dBm
Power Consumption
≤3.5W
Extinction Ratio
>3.5dB
DDM/DOM
Supported
Commercial Temperature Range
0 to 70°C (32 to 158°F)
