Single Port USB3.0 to Gigabit SFP Fiber Ethernet Media Converter

Name: Single Port USB3.0 to Gigabit SFP Fiber Ethernet Media Converter
Brand: E-link China Technology Co.,LTD
SKU: LNK-3011USB-SFP
Price: 64.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: E-link

Certification: ISO9001, CE, FCC, RoHS

Model Number: LNK-3011USB-SFP

Document: E-link Single Port USB2.0 ...V1.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: negotiation

Packaging Details: Industrial PoE Switch Standard Carton Packaging

Delivery Time: 7-10 working days

Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal

Supply Ability: 100000PCS/Month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Dimensions (LxWxH)::	9.61 In X 1.57 In X 0.73 In (24.4 Cm X 4 Cm X 1.85 Cm)	Supports System:	Win XP , Linux , Android 2.x , Android 4.x , Win 2000 , Win 2008 , Win Vista , Win7 32 , Win7 64 , Win8 32 , Win8 64 , MAC OS X
Operating Temperature::	0°C To 50°C (32°F To 122°F)	Weight:	0.06Kg

Dimensions (LxWxH)::	9.61 In X 1.57 In X 0.73 In (24.4 Cm X 4 Cm X 1.85 Cm)
Supports System:	Win XP , Linux , Android 2.x , Android 4.x , Win 2000 , Win 2008 , Win Vista , Win7 32 , Win7 64 , Win8 32 , Win8 64 , MAC OS X
Operating Temperature::	0°C To 50°C (32°F To 122°F)
Weight:	0.06Kg

Description

Single Port USB3.0 to Gigabit SFP Fiber Ethernet Media Converter

Product Advantages

· Converts USB3.0 to 1000Base SFP

· Supports external SFP

· Supports USB3.0, 2.0 and 1.1

· Supports CDC-ECM

· Supports LPM (Link Power Management)

· Supports pair swap/polarity/skew correction

· Crossover Detection & Auto-Correction

· Supports power down/link down power saving

· Supports hardware CRC (Cyclic Redundancy Check) function

· USB Powered and Data Transmission, no need external power supply

Technical Indexes

General
Brand:	E-link
Model:	LNK-3011USB-SFP
Quantity:	1pcs
Material:	Plastic + fiber + copper
Color:	Black or White
Specification
USB Port:	1 x USB 3.0
Optical Port:	1 x SFP 1000Base-FX
Transmission Rate:	1000Mbps
Chipset:	Realtek RTL8153-CG
Transmitted Power:	3.0W Max.
Supports System	Win XP , Linux , Android 2.x , Android 4.x , Win 2000 , Win 2008 , Win vista , Win7 32 , Win7 64 , Win8 32 , Win8 64 , MAC OS X
Environmental
Operating Temperature:	0°C to 50°C (32°F to 122°F)
Storage Temperature:	-40°C to 80°C (-40°F to 176°F)
Relative Humidity:	5% to 95% non-condensing
MTBF:	> 100,000 hrs
LED Indicators
1000FX (Per Port):	Link/Activity
Mechanical
Dimensions (LxWxH):	9.61 in x 1.57 in x 0.73 in (24.4 cm x 4 cm x 1.85 cm)
Weight:	0.06Kg
Casing:	Plastic Case
Mounting Options:	Desktop
Regulatory Approvals
ISO9001, CE, FCC, RoHS
FCC part 15,Class A

Overview

LNK-3011USB-SFP is a USB3.0 to Gigabit Fiber Ethernet Media Converter that supports external SFP modules and meets EN55022. It adopts Realtek RTL8153-CG 10/100/ 1000M Ethernet controller combining an IEEE 802.3u compliant Media Access Controller (MAC), USB 3.0 bus controller, and embedded memory. LNK-3011USB-SFP supports USB3.0 port and 1000M SFP port. Users can use different type of SFP modules (single-mode/multi-mode fiber, 1/2 core) as needed.

Ordering Information

Model	Description
LNK-3011USB-SFP	USB3.0 to 1000Base-FX SFP Ethernet Media Converter
SFP Options:	► (S) = SFP option. Please select your SFP option on our SFP Options page. ► SFP module is to be purchased separately.
Mounting Options:	► Desktop
Power Options:	► USB Powered
