1.25Gb/s 40km CWDM SFP Transceiver

Name: 1.25Gb/s 40km CWDM SFP Transceiver
Brand: E-link China Technology Co.,LTD
SKU: LNK-CSFP-1Gxx-40
Price: 395.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: E-link

Certification: ISO9001, CE, FCC, RoHS

Model Number: LNK-CSFP-1Gxx-40

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: Negotiated

Packaging Details: standard export package

Delivery Time: 3-12working days

Payment Terms: T/T,PayPal

Supply Ability: 1000pcs/mouth

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Product Type:	Transceiver	Temperature:	-20°C To~85°C
Distance:	2km	Case Size:	114 X 30 X 28 Mm

Product Type:	Transceiver
Temperature:	-20°C To~85°C
Distance:	2km
Case Size:	114 X 30 X 28 Mm

Description

1.25Gb/s 40km CWDM SFP Transceiver

Advantage

Ø Data-rate of 1.25Gbps operation

Ø 18-Wavelength CWDM DFB LD Transmitter from

Ø 1.25Gb/s 40km CWDM SFP Transceiver 0 1270nm to 1610nm, with Step 20nm

Ø Compliant with SFP MSA and SFF-8472

Ø Compatible with SONET OC-24-LR-1

Ø Compatible with RoHS

Ø +3.3V single power supply

Overview

The LNK-CSFP-1Gxx-40 series single mode transceiver is small form factor pluggable module

for duplex optical data communications such as Gigabit Ethernet 1000BASE-ZX and Fiber

Channel 1x SM-LC-L FC-PI. It is with the SFP 20-pin connector to allow hot plug capability.

This module is designed for single mode fiber and operates at a nominal wavelength of CWDM

wavelength. There are eighteen center wavelengths available from 1270nm to 1610nm, with

each step 20nm.

Application

Ø Gigabit Ethernet

Ø Fiber Channel Switch Infrastructure

Ø Router/Server interface

Ø Other optical transmission systems
