3G-SDI CWDM SFP Optical Transceiver 1270-1610nm 40km Digital Video MSA

Model: LNK-CWDM-SFP3G-XX40

 Product Description & Overview

The 3G-SDI CWDM 1270~1610nm 40km Digital Video SFP Optical Transceiver represents a high-

performance fiber optic solution designed for bandwidth-efficient video transmission systems. This

MSA-compliant transceiver module supports comprehensive 3G-SDI signal transmission across all

18 CWDM wavelengths from 1270nm to 1610nm, enabling significant expansion of existing fiber

infrastructure capacity without requiring additional fiber strands. The module maintains robust

performance with data rates ranging from 50Mbps to 2.97Gbps, ensuring reliable operation even

when processing challenging SDI pathological patterns.

Engineered to meet stringent industry standards, this optical transceiver delivers exceptional signal

integrity for SMPTE 259M, SMPTE 344M, SMPTE 292M, and SMPTE 424M serial interfaces while

achieving maximum transmission distances of 40 kilometers over single-mode fiber. The compact

SFP form factor provides flexible deployment options in various video transmission equipment,

including SDI extenders, video routers, and media converters. The module's sophisticated laser

technology ensures consistent performance across the entire CWDM spectrum, making it ideal

for dense wavelength division multiplexing applications in broadcast and professional video

environments.

Certified as Class I Laser products according to FDA/CDRH and IEC-60825 safety standards,

this transceiver guarantees safe operation in diverse installation scenarios. The advanced design

incorporates temperature-stabilized laser components that maintain precise wavelength accuracy

across varying environmental conditions. This reliability makes the module particularly suitable for

broadcast facilities, outside broadcast vehicles, sports venues, and surveillance systems requiring

high-density video transmission over extended distances. By leveraging CWDM technology, users

can effectively multiply their existing fiber capacity while maintaining the signal quality and reliability

essential for mission-critical video applications, establishing this transceiver as an optimal solution

for expanding video transmission capabilities in bandwidth-constrained environments.

Key Features Bullets

• SMPTE Standards Compliance
  Fully compatible with SMPTE 297-2006 specifications for professional video transmission

• Wide Bandwidth Operation
  Supports data rates from 50 Mbps to 2.97 Gbps for SD-SDI, HD-SDI and 3G-SDI applications

• Extended Reach Transmission
  Delivers reliable video transmission up to 40km over single-mode fiber at 3G-SDI rates

• Robust Signal Processing
  Maintains signal integrity with pathological pattern support for all SDI standards

• CWDM Wavelength Flexibility
  18-wavelength DFB transmitter covering 1270nm to 1610nm spectrum

• Hot-Pluggable Design
  Standard SFP footprint enables easy installation and replacement without system shutdown

• Industry Standard Compatibility
  Fully compliant with SFP MSA specifications for broad interoperability

• Advanced Monitoring Capabilities
  Digital diagnostic functions accessible via I2C interface for real-time performance monitoring

• Efficient Power Design
  Single +3.3V power supply with optimized low power consumption

• Extended Temperature Operation
  Operating case temperature range from 0°C to +70°C for stable performance

• Environmental Compliance
  Meets OHS requirements and lead-free manufacturing standards

Technical Specifications & Indexes

Ordering Information

Application Scenarios
