1.25Gbps SFP Bi-Directional Transceiver, 3km Reach 1310nm TX / 1550nm RX

Name: 1.25Gbps SFP Bi-Directional Transceiver, 3km Reach 1310nm TX / 1550nm RX
Brand: E-link China Technology Co.,LTD
SKU: Commercial Type: LNK-BSFP-1.25G-3CU Industrial Type: LNK-BSFP-1.25G-L3CU
Price: 395.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: E-link

Model Number: Commercial Type: LNK-BSFP-1.25G-3CU Industrial Type: LNK-BSFP-1.25G-L3CU

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Negotiation

Packaging Details: Carton Packaging

Delivery Time: 3-12 working days

Payment Terms: L/C,T/T,Western Union,MoneyGram,Paypal

Supply Ability: 1000 pcs/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      1.25Gbps SFP transceiver with 3km reach, Bi-directional SFP transceiver 1310nm TX, SFP fiber transceiver with 1550nm RX


Input Differential Impedance:	90~110Ω	Data Input Swing Differential:	400~1800mV
Optical Rise/Fall Time (20%~80%):	0.26ns	Average Output Power:	-10~-4dBm
Spectral Width (RMS):	4nm	Centre Wavelength:	1260~1360nm

Input Differential Impedance:	90~110Ω
Data Input Swing Differential:	400~1800mV
Optical Rise/Fall Time (20%~80%):	0.26ns
Average Output Power:	-10~-4dBm
Spectral Width (RMS):	4nm
Centre Wavelength:	1260~1360nm

Description

1.25Gbps SFP Bi-Directional Transceiver, 3km Reach 1310nm TX / 1550nm RX

Advantages

¨ Dual data-rate of 1.25Gbps/1.063Gbps operation

¨ 1310nm FP laser and PIN photodetector for 3km transmission

¨ 1.25Gbps SFP Bi-Directional Transceiver, 3km Reach 1310nm TX / 1550nm RX 0 Compliant with SFP MSA and SFF-8472 with simplex SC Receptacle

¨ Digital Diagnostic Monitoring:

Internal Calibration or External Calibration

¨ Compatible with SONET OC-24-LR-1

¨ Compatible with RoHS

¨ +3.3V single power supply

¨ Operating case temperature range of

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C

Overview

The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 3km transmission distance with SMF.

The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Technical Indexes

Parameter	Symbol	Min	Typical	Max	Unit
Tx Disable Negate Time	t_on			1	ms
Tx Disable Assert Time	t_off			10	µs
Time To Initialize, including Reset of Tx Fault	t_init			300	ms
Tx Fault Assert Time	t_fault			100	µs
Tx Disable To Reset	t_reset	10			µs
LOS Assert Time	t_loss_on			100	µs
LOS De-assert Time	t_loss_off			100	µs
Serial ID Clock Rate	f_serial_clock			400	KHz
MOD_DEF (0:2)-High	V_H	2		Vcc	V
MOD_DEF (0:2)-Low	V_L			0.8	V

Ordering Information

Part Number	Product Description
LNK-BSFP-1.25G-3CU	1.25Gbps SFP Bi-Directional Transceiver, 1310TX/1550RX, SC 3km, 0°C~+70°C,With Digital Diagnostic Monitoring
LNK-BSFP-1.25G-L3CU	1.25Gbps SFP Bi-Directional Transceiver, 1310TX/1550RX, SC 3km,-40°C~+85°C,With Digital Diagnostic Monitoring
