1.25Gbps SFP Bi-Directional Transceiver, 60km Reach 1490nm TX / 1550nm RX

Name: 1.25Gbps SFP Bi-Directional Transceiver, 60km Reach 1490nm TX / 1550nm RX
Brand: E-link China Technology Co.,LTD
SKU: Commercial Type: LNK-BSFP-1.25G-60CU Industrial Type: LNK-BSFP-1.25G-L60CU
Price: 395.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: E-link

Model Number: Commercial Type: LNK-BSFP-1.25G-60CU Industrial Type: LNK-BSFP-1.25G-L60CU

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Negotiation

Packaging Details: Carton Packaging

Delivery Time: 3-12 working days

Payment Terms: L/C,T/T,Western Union,MoneyGram,Paypal

Supply Ability: 1000 pcs/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      1.25Gbps SFP transceiver 60km reach, Bi-Directional SFP transceiver 1490nm TX, SFP fiber transceiver with 1550nm RX


Input Differential Impedance:	90~110Ω	Data Input Swing Differential:	400~1800mV
Optical Rise/Fall Time (20%~80%):	0.26ns	Average Output Power:	-2~+3dBm
Spectral Width (RMS):	1nm	Centre Wavelength:	1470~1510nm

Input Differential Impedance:	90~110Ω
Data Input Swing Differential:	400~1800mV
Optical Rise/Fall Time (20%~80%):	0.26ns
Average Output Power:	-2~+3dBm
Spectral Width (RMS):	1nm
Centre Wavelength:	1470~1510nm

Description

1.25Gbps SFP Bi-Directional Transceiver, 60km Reach 1490nm TX / 1550nm RX

Advantages

¨ Dual data-rate of 1.25Gbps/1.063Gbps operation

¨ 1490nm DFB laser and PIN photodetector for 60km transmission

¨ 1.25Gbps SFP Bi-Directional Transceiver, 60km Reach 1490nm TX / 1550nm RX 0 Compliant with SFP MSA and SFF-8472 with simplex SC

¨ Digital Diagnostic Monitoring: Internal Calibration or External Calibration

¨ Compatible with SONET OC-24-LR-1

¨ Compatible with RoHS

¨ +3.3V single power supply

¨ Operating case temperature range of 0°C to +70°C (Commercial) or -40°C to +85°C (Industrial)

Overview

The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 60km transmission distance with SMF.

The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Technical Indexes

Parameter		Symbol		Min	Typical	Max	Unit	Notes
Transmitter
Centre Wavelength			λc	1470	1490	1510	nm
Spectral Width (-20dB)			∆λ			1	nm
Side Mode Suppression Ratio			SMSR	30			dB
Average Output Power			Pout	-2		+3	dBm	1
Extinction Ratio			ER	9			dB
Optical Rise/Fall Time (20%~80%)			t_r/t_f			0.26	ns
Data Input Swing Differential			V_IN	400		1800	mV	2
Input Differential Impedance			Z_IN	90	100	110	Ω
TX Disable	Disable			2.0		Vcc	V
TX Disable	Enable			0		0.8	V
TX Fault	Fault			2.0		Vcc	V
TX Fault	Normal			0		0.8	V
Receiver
Centre Wavelength			λc	1530		1570	nm
Receiver Power Low						-25	dBm	3
Receiver Power High				0			dBm	3
Receiver Overload				0			dBm	3
LOS De-Assert			LOS_D			-25	dBm
LOS Assert			LOS_A	-35			dBm
LOS Hysteresis				1		4	dB
Data Output Swing Differential			Vout	400		1800	mV	4
LOS			High	2.0		Vcc	V
LOS			Low			0.8	V

Ordering Information

Part Number	Product Description
LNK-BSFP-1.25G-60CU	1.25Gbps SFP Bi-Directional Transceiver, 1490TX/1550RX, SC 60km, 0°C~+70°C,With Digital Diagnostic Monitoring
LNK-BSFP-1.25G-L60CU	1.25Gbps SFP Bi-Directional Transceiver, 1490TX/1550RX, SC 60km,-40°C~+85°C,With Digital Diagnostic Monitoring
