Product Details
Place of Origin: China
Brand Name: E-link
Certification: ROHS,FCC,CE
Model Number: LNK-IRS422-C02-FC
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: Fiber Modem Standard Export Package
Delivery Time: 5-12 working days
Payment Terms: T/T, Western Union, MoneyGram, Paypal
Supply Ability: 1000 pcs/month
Keyword: |
Serial To Fiber Converter |
Connector Type: |
SC/FC/ST |
Data Type: |
2Ch RS422 Bi-Direction |
RS-422 Signals: |
Tx+, Tx-, Rx+, Rx-, GND |
Fiber Type: |
Single-mode/Multi-mode |
Transmission Distance: |
2Km/20Km |
Keyword: |
Serial To Fiber Converter |
Connector Type: |
SC/FC/ST |
Data Type: |
2Ch RS422 Bi-Direction |
RS-422 Signals: |
Tx+, Tx-, Rx+, Rx-, GND |
Fiber Type: |
Single-mode/Multi-mode |
Transmission Distance: |
2Km/20Km |
Fiber Modem Industrial 2 Channel RS422 Serial To Fiber Converter FC Port 1310nm
FC Port Serial to Fiber Converter Advantages
► Fan-less and Din-Rail design for Harsh Industrial Environment
► Built in Bi-Directional RS422 (Terminal Block) Serial Port
► Serial data is fully transparent, baud rate is self-adaptive, no setting is required
► Supports Input Voltage 12 ~ 48VDC
RS422 to Fiber Modem Technical Indexes
|
Fiber Optical Interface |
|
|
Fiber interface |
SFP, FC, SC or ST |
|
Cable requirement |
Multi-Mode: 50/125um, 62.5/125um Single-Mode: 9/125um |
|
Fiber port |
1 Fiber Port |
|
Transmission distance |
Multi-Mode: 2km Single-Mode: 20km |
|
RS422 Serial Interface |
|
|
Physical interface |
Industrial standard screw terminal |
|
Data type |
Up to 2Ch RS422 Bi-Direction |
|
RS-422 signals |
Tx+, Tx-, Rx+, Rx-, GND |
|
Serial port line distance (copper) |
1000 meters |
|
Baud Rate |
0 ~ 800kbps |
|
Power Requirements |
|
|
Power input |
12~48VDC |
|
Power consumption |
<6W |
|
Power connector |
Terminal block |
|
Power protection |
Reverse polarity protection |
|
LED Indicator |
|
|
PWR |
Power Supply |
|
FL |
Fiber Link Status |
|
Data 1~16 |
Serial Data Signal |
RS422 Serial to Fiber Converter Overview
E-link LNK-IRS series is an industrial grade 2-Channel RS422 to fiber optic converter which converts a standard RS422 signal to a fiber optic link as to extend the signal up to 2KM on multimode fiber and 20KM on single mode fiber. It features a Din-Rail Type design to give users an easy installation and maintenance purpose in any harsh industrial environments.
RS422 to Fiber Optic Converter Ordering Information
| Part Number | Description |
|
LNK-IRS422-C02-FC
|
Industrial 2Ch RS-422 Serial to Fiber Converter, Multi-Mode, 1310nm, Dual Fiber, 2KM, FC, -40°C ~ 80°C |
|
LNK-IRS422-C02-FC-20
|
Industrial 2Ch RS-422 Serial to Fiber Converter, Single-Mode, 1310nm, Dual Fiber, 20KM, FC, -40°C ~ 80°C |
|
LNK-IRS422-C02-FC-S20A |
Industrial 2Ch RS-422 Serial to Fiber Converter, Single-Mode, Single Fiber, 1310nm Tx/1550nm RX, 20KM, FC, -40°C ~ 80°C |
|
LNK-IRS422-C02-FC-S20B |
Industrial 2Ch RS-422 Serial to Fiber Converter, Single-Mode, Single Fiber, 1550nm Tx/1310nm RX, 20KM, FC, -40°C ~ 80°C |
