4K 30HZ HDMI Fiber Extender 120M Support Local Loopout In Sender

Product Details

Place of Origin: China

Brand Name: E-link

Certification: ROHS,FCC,CE

Model Number: LNK-4KE-120KVM

Payment & Shipping Terms

Minimum Order Quantity: 1 pair

Price: Negotiation

Packaging Details: HDMI Video Extender Standard Export Package

Delivery Time: 5-12 working days

Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal

Supply Ability: 1000 pairs/month

Get Best Price
Contact Now
Specifications
Highlight:

4K 30HZ HDMI Fiber Extender

,

120M HDMI Fiber Extender

,

120M Extender Kvm Hdmi

Name:
4K@30HZ HDMI KVM Extender 120M With Loopout
Model:
LNK-4KE-120KVM
The Warranty:
1 Year Free Warranty
Dimension:
82*85*17mm
Audio Format:
LPCM, Dolby Digital, DTS, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio
Cable Type:
Single-mode Fiber
Data Rate:
Up To 10.2Gbps
HDCP Version:
HDCP 1.4
HDMI Version:
HDMI 1.4
Input/Output Interface:
HDMI, Fiber
Net Weight:
0.2KG
Operating Temperature:
0℃~+70℃
Power Supply:
DC 5V/1A
Product Name:
HDMI Fiber Extender
Storage Temperature:
-20℃~+85℃
Transmission Distance:
Up To 20km
Video Resolution:
Up To 4K@60Hz 4:4:4
Name:
4K@30HZ HDMI KVM Extender 120M With Loopout
Model:
LNK-4KE-120KVM
The Warranty:
1 Year Free Warranty
Dimension:
82*85*17mm
Audio Format:
LPCM, Dolby Digital, DTS, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio
Cable Type:
Single-mode Fiber
Data Rate:
Up To 10.2Gbps
HDCP Version:
HDCP 1.4
HDMI Version:
HDMI 1.4
Input/Output Interface:
HDMI, Fiber
Net Weight:
0.2KG
Operating Temperature:
0℃~+70℃
Power Supply:
DC 5V/1A
Product Name:
HDMI Fiber Extender
Storage Temperature:
-20℃~+85℃
Transmission Distance:
Up To 20km
Video Resolution:
Up To 4K@60Hz 4:4:4
Description
4K 30HZ HDMI Fiber Extender 120M Support Local Loopout In Sender

4K 30HZ HDMI Fiber Extender 120M Support Local Loopout In Sender



4K@30HZ HDMI KVM Extender 120M with Loopout

  • Aluminum alloy housing design, stable and durable ;compact size and Slim ,strong
  • anti-interference, Wall-mounted type is more convenient;
  • Uncompressed transmits HDMl video and audio signals up to 120M over a single CAT6a/7cable;
  • Support video resolution up to 3840*2160@30Hz 3D signal:
  • Support Keyboard and mouse control;
  • Support local loopout in sender
  • HDMI 1.4 and HDCP 1.4 standard;
  • Build-in EDID function, can match many kind display device;
  • Ethernet cables with a standard IEEE - 568b connection, convenient installation;
  • Built-in esD protection
  • High compatibility, can auto-match source and display device:Built-in automatic adjustment svstem, make the image smooth, clear and stable

Technical Indexes

Parameter Description
Video Standards HDMI1.4; HDCP 1.4
Maximum pixel clock 225MHz
Maximum data rate 10.2Gbps
Maximum resolution 3840*2160@30Hz (backward-compatible)
Connector HDMI-A
Impedance 100Ω
USB Interface

PC: Standard USB-A
K/M: Standard USB-A

USB Signal HID Signal
UTP Interface RJ45 (IEEE - 568b connection)
Transmission distance CAT6-120M
Other Power supply The power adapter: DC 5V
Power dissipation MAX 4W
Temperature Operating: -5℃ ~ +70℃
Humidity Operating: 5% ~ 90%
Dimension 82*85*17mm
The warranty 1 year free warranty



Overview
This LNK-4KE-120KVM includes a transmitter unit (TX) and a receiver unit(RX), working as a pair. It allows for transmission and extension uncompressed full HD 4K@30Hz HDMI signal via CAT6/6A/7 network cable, the transmission distance is up to 120 meters with zero latency. At the same time, the signal is stable, and the built-in EDID greatly improves the compatibility of the device. Support Keyboard mouse control and local loopout . This product is perfect for AV transmission in applications of HD conference system, HD video shooting, HD multimedia education system, HD digital advertising and signage etc.
The device has a long transmission distance, low use cost, convenient installation and good compatibility, and it is a stable and efficient transmission method.
4K 30HZ HDMI Fiber Extender 120M Support Local Loopout In Sender 0
Ordering Information


Part No Description of product
LNK-4KE-120KVM 4K@30HZ HDMI KVM Extender With Loopout - 395 ft (120m)
