Product Details
Place of Origin: China
Brand Name: E-link
Certification: CE
Model Number: LNK-16BRCA-20
Payment & Shipping Terms
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Micro Mini SFP Media Converter Standard Carton Packaging
Delivery Time: 3-5 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, PayPal
Supply Ability: 1000000PCS/Month
Input Power:: |
DC 12V@1A |
Power Adapter:: |
AC 90V~240V |
Power Consumption:: |
5W Max. |
Dimension: |
80mm*70mm*26mm |
Connector Type: |
SC/FC/ST |
Data Rate: |
10/100/1000Mbps |
Humidity: |
5%~90% |
Interface Type: |
RJ45/SC/FC/ST |
Operating Temperature: |
-40℃~+85℃ |
Power Consumption: |
3W |
Power Supply: |
AC/DC |
Product Name: |
Fiber Media Converter |
Storage Temperature: |
-40℃~+85℃ |
Transmission Distance: |
2KM/20KM/40KM/60KM/80KM/100KM |
Warranty: |
3 Years |
Wavelength: |
850/1310/1550nm |
Weight: |
0.2KG |
Input Power:: |
DC 12V@1A |
Power Adapter:: |
AC 90V~240V |
Power Consumption:: |
5W Max. |
Dimension: |
80mm*70mm*26mm |
Connector Type: |
SC/FC/ST |
Data Rate: |
10/100/1000Mbps |
Humidity: |
5%~90% |
Interface Type: |
RJ45/SC/FC/ST |
Operating Temperature: |
-40℃~+85℃ |
Power Consumption: |
3W |
Power Supply: |
AC/DC |
Product Name: |
Fiber Media Converter |
Storage Temperature: |
-40℃~+85℃ |
Transmission Distance: |
2KM/20KM/40KM/60KM/80KM/100KM |
Warranty: |
3 Years |
Wavelength: |
850/1310/1550nm |
Weight: |
0.2KG |
16Ch Bidirectional Level Converter RCA Audio Over Fiber Ethernet To Optical
Installation 16Ch Bi-directional RCA Audio over Fiber Optical Converter
Advantages:
► Send 16Ch Bi-Directional RCA Audio of 24-Bit Digitally Encoded Broadcast Quality Audio
► Send your RCA Audio Signal for distances of up to 12.4 miles (20 km) over SINGLE MODE optical fiber
► Plug & Play - Simply Plug in an Optical FC port and RCA audio
► Support Point-to-Point or Multi-Point connection
► No Loss, No Delay, Fiber Optica Audio Signal Transmission
► No need to configuration or any adjusting during the installation, user friendly design
► Full Set includes Optical Fiber to RCA transmitter, receiver & AC power supply, plus user manual
Technical Indexes
| RCA Audio | |
| Connector: | RCA |
| Input/output Impedance: | 600ohm(unbalance) |
| Max input/output voltage: | 3.0Vp-p |
| Frequency Response: | 10 Hz~29kHz @±3dB |
| SNR: | ≥88db |
| Audio digital bandwidth: | 24 bit |
| Optical Fiber | |
| Number of Optical Port: | 1 |
| Optical Connector: | Simplex FC (Default) |
| Wavelength: | 1310/1550nm |
| Optical Fiber: | Single Mode: 9/125um |
| Distance: | 0~20km (SMF) / 0~2km (MMF) |
| Electrical and Mechanical | |
| Input Power: | DC 12V@1A |
| Power Adapter: | AC 90V~240V |
| Power Consumption: | 5W Max. |
| LED Indicators: | |
| PWR: | Power Status |
| SYNC: | Fiber Status |
| Dimensions (WxDxH): | 480 x 185 x 50 mm |
| Weight: | 9.8Kg (including Transmitter & Receiver) |
| Casing: | Metal Case |
| Mounting Options: | Rack-mount |
| Environmental | |
| Operating Temperature: | -20°C to 80°C (-4°F to 176°F) |
| Storage Temperature: | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity: | 5% to 95% non-condensing |
| MTBF | > 100,000 hrs |
| Regulatory Approvals | |
| ISO9001, CE, FCC, RoHS | |
Overview
E-link 16Ch Bi-Directional RCA Audio over Fiber Optical Converter for CCTV audio and Professional Grade AV audio transmission over single mode and multimode fibers over distances up to 20 km and more. Support 16 Channel Bi-Directional 24-bit digitally encoded broadcast quality audio over one multi-mode or single-mode optical fiber. These fiber optic transmitter and fiber optic receiver are typically used in applications for Rental, Staging, Theater, Stadiums, Theme Parks, Broadcast/Studio, CCTV audio and Professional AV applications, etc, and are available for stand-alone or rack-mount installations. Plug and Play design ensures adjustment-free installation and operation, and optical adjustments are never required. LED indicators are provided to instantly monitor the system operating status.
Ordering Information
| Model | Description |
| LNK-16BRCA-20 | 16Ch BiDi (Forward + Backward) RCA Audio over Fiber Optical Converter, 20km, single mode single fiber, FC, including 1 transmitter & 1 receiver, used by pairs |
