USB VGA KVM Fiber Optic Extender
USB VGA KVM Fiber Optic Extender
USB VGA KVM Fiber Optic Extender Advantage
► Transmits VGA video signals up to 10km over one fiber optic cable;
► Support video resolution up to 1920*1080P@60Hz;
► Support keyboard and mouse signal transmission;
► Support external stereo audio unidirectional transmission;
► Support transmitter one channel signal output;
► Support RS232 signal unidirectional transmission, baud rate self-adaptive;
► High compatibility, can auto-match source and display device;
► Built-in automatic adjustment system, make the image smooth, clear and stable;
► Built-in ESD protection system;
► Simple to install, plug and play;
USB VGA KVM Fiber Optic Extender Overview
The LNK-FVGA-KVM Fiber optic extender provides extension of VGA signals long distances transmission
over one fiber optic cable, it supports high resolution up to 1080P, KVM, transmitter local output, RS232
signal and external audio transmission function. The extender can use for a wide range of applications that
requiring long distance transmission of high resolution with high quality by its good stability and powerful security.
USB VGA KVM Fiber Optic Extender Technical Indexes
|
Parameter
|
Description
|
|
Video
|
Standards
|
VGA
|
|
Maximum pixel clock
|
380MHz
|
|
Resolution
|
1920x1200@60Hz / 1920x1080@60Hz
1600x1200@60Hz / 1680x1050@60Hz
1280x1024@60Hz / 1280x1024@75Hz
1280x800@60Hz / 1280x768@60Hz
1280x720@60Hz / 1024x768@60Hz
1024x768@75Hz / 800x600@60Hz/75Hz
|
|
Impedance
|
75Ω
|
|
Audio
|
Interface
|
3.5mm earphone seat
|
|
Format
|
44.1K,48K,96K,176K,192K
|
|
Signal type
|
Stereo
|
|
K/M
|
Interface
|
To PC: MINI-USB
To keyboard and mouse: USB-A
|
|
RS232
|
Interface
|
Industrial terminal
|
|
Signal direction
|
Bidirectional
|
|
Baud rate
|
Self-adaptive, Max:115200bps
|
|
Data bits
|
8
|
|
Optical fiber
|
Interface
|
LC connector
|
|
Fiber type
|
Single-mode single fiber
|
|
Wavelength
|
Single-mode 1310nm
|
|
Interface bandwidth
|
2.97Gbps
|
|
Transmission distance
|
standard 10km
|
|
Other
|
Power supply
|
The power adapter: DC 12V/1A
|
|
Power dissipation
|
MAX 6W
|
|
Temperature
|
Operating: -5℃ ~ +70℃
|
|
Humidity
|
Operating: 5% ~ 90%
|
|
Dimension
|
155*115*30mm
|
|
The warranty
|
1 year free warranty, life-long maintenance
|
USB VGA KVM Fiber Optic Extender Ordering Information
|
Model
|
Details
|
|
LNK-FVGA-KVM -T
|
1080P VGA KVM Fiber Optic Extender Transmitter
|
|
LNK-FVGA-KVM -R
|
1080P VGA KVM Fiber Optic Extender Receiver
|
USB VGA KVM Fiber Optic Extender Picture
