Multi-Channel Embedded Audio: Each video channel carries up to 8 channels of embedded digital audio, ensuring perfect synchronization for professional broadcasting and audio-for-video applications.
Automatic Signal Integrity Management: Features automatic cable equalization and re-clocking technology for a wide range of data rates from 270Mbit/s to 3Gbit/s, guaranteeing a stable and robust signal free from degradation.
Extended Fiber Optic Reach: Leverages single fiber technology to achieve exceptional long-distance transmission, reliably covering distances from 10 km up to 80 km, ideal for city-wide surveillance and remote broadcast feeds.
Robust Industrial-Grade Design: Engineered with an ultra-broad temperature range (-40℃ to +85℃), this converter delivers unwavering performance and reliability in harsh outdoor and industrial environments.
Advanced Wavelength Division Multiplexing (WDM): Supports efficient fiber network integration using WDM, CWDM, and DWDM techniques, allowing multiple signals over a single fiber strand for cost-effective system expansion.
True Broadcast-Level Quality: Utilizes full digital, non-compression signal transmission from end to end, preserving the original video quality without any loss for critical monitoring and production work.
Superior Optical Performance: Boasts a wide optic dynamic range that requires no manual adjustment, simplifying installation and ensuring stable optical link performance.
Seamless HD-SDI System Integration: Offers direct plug-and-play compatibility with existing HD-SDI camera systems, providing a straightforward upgrade path to fiber optic connectivity.
High-Capacity & Future-Proof Link: Provides 1000M optical fiber transmission bandwidth, ensuring a ready pathway for future system upgrades to higher data rates.
Uninterrupted Operation & Maintenance: Designed with hot-swap capability and a secure terminal block for power input, facilitating easy installation and maintenance without system downtime.
Application Scenarios
1.Broadcast & Live Event Production:
Field Production & Outside Broadcast (OB) Vans: Enables long-haul transport of uncompressed HD-SDI signals from camera heads to the production switcher over a single fiber.
Studio & Sports Venue Links: Creates robust fiber optic backbones for transmitting camera feeds, ensuring signal integrity and zero latency for live switching and broadcast.
Signal Distribution: Facilitates the routing of 3G-SDI/HD-SDI sources to multiple control rooms or display locations across a facility.
2.Professional Security & Surveillance Systems:
Long-Distance CCTV Infrastructure: Ideal for city-wide surveillance, traffic monitoring, and perimeter security for airports, ports, and critical infrastructure, transmitting 1080p video over distances up to 80km.
PTZ Camera Control: The integrated bi-directional RS422/485 data channel allows for seamless remote control of Pan-Tilt-Zoom (PTZ) cameras over the same fiber link.
Hardened Environments: The industrial-grade, wide-temperature design (-40℃ ~ +85℃) ensures reliable operation in extreme outdoor conditions, from deserts to arctic climates.
3.Large-Scale AV & Command & Control Rooms:
Digital Signage Networks: Distributes high-quality video content to displays across vast campuses, corporate headquarters, or public transportation hubs.
Control Room Visualization: Provides a pristine and reliable video feed from data sources or cameras to large-scale video walls and monitoring displays, crucial for operation centers and emergency response facilities.
4.Fiber-Optically Converged Networks:
Bandwidth Efficiency: Supports WDM/CWDM/DWDM technology, allowing multiple video, audio, and data streams to be multiplexed onto a single fiber, maximizing infrastructure investment and simplifying cable management.
Future-Proof Upgrades: The 1000M optical bandwidth provides a clear migration path for future system upgrades to higher-resolution formats like 4K.
Technical Indexes
|
Fiber Optical interface
|
|
Fiber interface
|
Simplex FC
|
|
Transmission distance
|
550m-20Km
|
|
Wavelength
|
1310nm/1550nm
|
|
Video
|
|
Video interface
|
BNC
|
|
Video input/output impedance
|
75Ω
|
|
Video input/out put voltage
|
Typical:1Vpp, Min 0.5Vpp, Max 1.5Vpp
|
|
Video Bits Rate
|
Max 3.2Gb/s
|
|
Differential gain (10%～90% APL)
|
<1%
|
|
Video SDI standard
|
270Mbps(SD-SDI), 1.485Gbps/M(HD-SDI)
|
|
|
SMPTE425M3Gb/s Mapping(3G-SDI)
|
|
|
SMPTE424M 3Gb/s serial interface(3G-SDI)
|
|
Data
|
|
Physical interface
|
Industrial standard screw terminal
|
|
Data type
|
RS422/RS485 Reverse Direction
|
|
Frequency/Rate support
|
Max. 115200bps for RS422
Max. 57600bps for RS485
|
|
BER
|
<10ˉ9
|
|
Electrical
|
|
Power adaptor
|
DC 5~25V
|
|
Power consumption
|
<5W
|
|
LED Indicator
|
|
P/S
|
Power Supply
|
|
DAT
|
Data
|
|
Mechanical
|
|
Dimensions (LxWxH)
|
120 x 105 x 28 mm
|
|
Weight
|
0.43KG/pair
|
|
Casing
|
Aluminum Case
|
|
Mounting Options
|
Wall-mount
|
|
Environmental
|
|
Working Temperature
|
-20℃～+70℃
|
|
Storage Temperature
|
-40℃～+80℃
|
|
Working Humidity
|
0~95%
|
|
MTBF
|
≥100000 hours
|
