12G-SDI to HDMI 2.0 Converter

Name: 12G-SDI to HDMI 2.0 Converter
Brand: E-link China Technology Co.,LTD
SKU: LNK-CSH-12G
Price: 594.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: E-link

Certification: ROHS,FCC,CE

Model Number: LNK-CSH-12G

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Negotiation

Packaging Details: Converter Standard Export Package

Delivery Time: 3-12 working days

Payment Terms: L/C,T/T,Western Union,MoneyGram,Paypal

Supply Ability: 1000 pcs/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                  SDI HDMI 2.0 Converter, 12G-SDI HDMI 2.0 Converter


Keywords:	HDMI Converter	Operating Temperature:	0 To 55℃
Dimensions (W X D X H):	253 X 162.5 X 40mm	Shippingweight:	1030g
Humidity:	Less Than 95℃

Keywords:	HDMI Converter
Operating Temperature:	0 To 55℃
Dimensions (W X D X H):	253 X 162.5 X 40mm
Shippingweight:	1030g
Humidity:	Less Than 95℃

Description

12G-SDI to HDMI 2.0 Converter

12G-SDI to HDMI 2.0 Converter Advantages

► Convert 12G-SDI to HDMI 2.0b at up to 4K 60p

► SDI supports up to 12G-SDI, support 4:2:2 HDMI2.0 output

► The highest resolution is 4K 60HZ, which can be down-converted to 1080P 60HZ

► Support audio embedding and de-embedding, compatible with AES/RCA audio

► SDI supports 8 Channels for embedded audio

► Support HDMI HDCP ON and OFF

► Fiber SFP port available, support 12G remote transmission

► Support phantom power

12G-SDI to HDMI 2.0 Converter Overview

The LNK-CSH-12G is a 12G-SDI to HDMI 2.0 Converter that converts HD/3G/6G/12G-SDI input signals to an HDMI output in real time. It supports various transmission distances depending on different SDI formats, including 45 m (12G-SDI), 60 m (6G-SDI), 90 m(3G-SDI), and 150 m (HD-SDI), offering the flexibility for professional video projects. In addition, It’s with Fiber SFP port available, support 12G remote transmission. The LNK-CSH-12G is a perfect choice for converting SDI signal to HDMI for applications such as broadcasting, medical imaging and industrial inspection.

12G-SDI to HDMI 2.0 Converter Technical Indexes

Input Interface	1 x 75Ω BNC, 1 x Video SMPTE SFP+
Output Interface	1 x HDMI Type A, 1 x 75Ω BNC, 1 x Video SMPTE SFP+
Audio Interface	2 x XLR Male Jack
	2 x XLR Female Combo 6.4 Jack
	2 x 10KΩ RCA
Transmission Distance	Fiber SFP	10KM
	12G-SDI	40M
	3G-SDI	100M
	HD-SDI	200M

12G-SDI to HDMI 2.0 Converter Ordering Information

Model	Description
LNK-CSH-12G	12G-SDI to HDMI 2.0 Converter, broadcast level, support audio embedding and de-embedding, compatible with AES/RCA audio, Fiber SFP port available (not including SFP modules)
