Product Details
Place of Origin: China
Brand Name: E-link
Certification: ROHS,FCC,CE
Model Number: LNK-12GSDI-1V2R1GE
Payment & Shipping Terms
Minimum Order Quantity: 1 pair
Price: Negotiation
Packaging Details: SDI Fiber Optic Extender Standard Export Package
Delivery Time: 5-12 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 1000 pairs/month
Keyword: |
Ethernet Over Fiber Converter |
Resolution Range: |
3840 X 2160@60Hz |
Ethernet: |
10/100/1000Mbps Gigabit |
Data Type: |
2Ch Backward RS485 |
Input: |
1 X 12G-SDI On BNC |
Fiber Port: |
2 X FC Optical Fiber |
Keyword: |
Ethernet Over Fiber Converter |
Resolution Range: |
3840 X 2160@60Hz |
Ethernet: |
10/100/1000Mbps Gigabit |
Data Type: |
2Ch Backward RS485 |
Input: |
1 X 12G-SDI On BNC |
Fiber Port: |
2 X FC Optical Fiber |
12G SDI Video Fiber Converter With Gigabit Ethernet And 2Ch Backward RS485 FC Fiber
SDI Fiber Transceiver Advantages
► Directly compatible with 12G/6G/3G-SDI camera systems
► Long transmission capability up to 80 km
► Full digital non-compression broadcast level transmission
► Super optic dynamic range and free of adjustment
► Fiber optic WDM/CWDM/DWDM technique
Video Fiber Transmitter Receiver Technical Indexes
|
Formats |
Supports ST-2082-1(12G), ST-2081-1(6G), ST-424(3G), ST-292(HD) And ST-259(SD) |
|
Compatible |
Compatible With DVB-ASI and AES10 (MADI) |
|
Input |
1 x 12G-SDI on BNC |
|
Output |
2 x FC optical fiber |
|
1 x 12G-SDI loop-out on BNC |
|
|
Supported Resolution |
HDTV 4K*2K, 1080P, 1080I, 720P |
|
Resolution range |
3840*2160@60Hz |
|
Input cable specification |
≤70m@12G SDI Belden 1694A |
|
Output cable specification |
≤60m@12G SDI Belden 1694A |
|
Ethernet |
10/100/1000Mbps |
|
Data type |
2Ch Backward RS485 |
|
Optical transmission bandwidth |
270MHz～12GHz |
|
Power |
12 VDC |
|
Power Consumption |
6 W (Max.) |
|
Dimensions (LxWxH) |
117 x 80 x 24 (mm) |
|
Operating Temperature |
-10℃～70℃ |
|
Storage Temperature |
-40℃～85℃ |
Ethernet Over Fiber Extender Overview
LNK-12GSDI-1V2R1GE Series 12G-SDI Fiber Converter supports 1Ch 12G Video (audio embedded) &1Ch Gigabit Ethernet&2Ch Backward RS485 transmitted via fiber optical cable, and monitor the signal locally over a 12G loop output. E-link 12G Video over Fiber Converters includes one transmitter and one receiver for HDTV 4K*2K(3840*2160@60Hz), 1080P,1080I, 720P.
Ordering Information
|
Model |
Description |
|
LNK-12GSDI-1V2R1GE |
12G-SDI to Fiber Converter with Gigabit Ethernet and 2Ch Backward RS485, SMF, LC Fiber Connector 10KM, including Transmitter and Receiver, used by pairs |
