OSW Series MEMS Optical Switch

Name: OSW Series MEMS Optical Switch
Brand: E-link China Technology Co.,LTD
SKU: LNK-OSW
Price: 130.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: E-link

Certification: CE, FCC, RoHS，ISO9001

Model Number: LNK-OSW

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: Negotiated

Packaging Details: standard export package

Delivery Time: 5-12working days

Payment Terms: T/T,PayPal

Supply Ability: 1000pcs/mouth

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Resolution:	1920*1080@60Hz	Distance:	Depend On SFP+ Modules Used, 20km Recommended.
Power Supply:	12~48VDC (Non PoE) 48~57VDC (PoE)	Dimensions:	150 X 115 X 50 Mm
Weight:	0.6Kg	Operating Temperature:	-40°C To 80°C (-40°F To 176°F)

Resolution:	1920*1080@60Hz
Distance:	Depend On SFP+ Modules Used, 20km Recommended.
Power Supply:	12~48VDC (Non PoE) 48~57VDC (PoE)
Dimensions:	150 X 115 X 50 Mm
Weight:	0.6Kg
Operating Temperature:	-40°C To 80°C (-40°F To 176°F)

Description

OSW Series MEMS Optical Switch

OSW Series MEMS Optical Switch

OSW Series MEMS Optical Switch Advantage

· 1 x 10G SFP+ fiber optical port

· 10 x Gigabit Ethernet ports, PoE optional

· supports RJ45 ports 10/100/1000M and Full Duplex/Half Duplex auto-negotiation

· Not support VLAN

OSW Series MEMS Optical Switch Overview

MEMS OSW is based on micro-electro-mechanical system (MEMS) technology, which achieved low insertion loss and highly repeatability by rotating the mirror of MEMS chip.

MEMS OSW is mainly used in optical cross and connection (OXC) system, optical add/drop system, measure instrument system and optical signal monitoring system.

The products are Telcordia GR-1312-CORE qualified, and RoHS ompliant.

OSW Series MEMS Optical Switch Technical Indexes

Parameter	Specification	Unit	Note
Wavelength Range	1260~1620	nm
Insertion Loss	1.0 & 1.2	dB	@1x4 & @1x8
Crosstalk	≥50	dB	For Single Mode
Return loss	≥45	dB	For Single Mode
Switching time	≤10	ms
Polarization Dependent Loss	≤0.2	dB
Wavelength Dependent Loss	≤0.3	dB	@<0 dB Att.
Return loss	≥45	dB	For Single Mode
Optical Power Handing	500	mW
Driving Voltage	60	V
Power Consumption	≤2	mW
Operation Temperature	-5~70	℃
Storage Temperature	-40~85	℃

OSW Series MEMS Optical Switch Ordering Information

LNK-OSW

LNK=E-link

O=Optical

S=Switch

W=MEMS

Port Configuration

Voltage Type

Switch Type

Wavelength

Fiber Type

Pigtail Type

Fiber Length

Connector

02=1x2

04=1x4

08=1x8

16=1x16

03=3V

60=60V

Non-Latching

1=1310nm

2=1550nm

3=1260~1620nm

4=850

1=SMF-28

2=MM50/125

3=62.5/125

X=Special

B=bare fiber

L=loose Tube

05=0.5m

10=1.0m

15=1.5m

0=None

1=FC/UPC

2=FC/APC

3=SC/UPC

4=SC/APC

5=LC/UPC

6=LC/APC
