12G-SDI Fiber Converter with Gigabit Ethernet 2Ch RS485 80km 4K Transmission

Model: LNK-12GSDI-1V2R1GE Series

 Product Description & Overview

The 12G-SDI to Fiber Converter with Gigabit Ethernet and 2Ch Backward RS485 represents a cutting-edge

solution for ultra-high-definition video transmission in professional broadcast and production environments.

This advanced fiber optic system supports single-channel 12G-SDI video transmission with embedded audio,

complemented by Gigabit Ethernet connectivity and dual-channel bidirectional RS485 data communication

through single-mode fiber infrastructure. The integrated 12G-SDI loop output enables real-time local monitoring

while maintaining signal integrity throughout the transmission path.

Engineered to meet the demanding requirements of 4K production, this converter pair delivers exceptional

video quality supporting resolutions up to 3840×2160@60Hz while maintaining backward compatibility with

1080P, 1080I, and 720P formats. The system employs advanced fiber optic technology to ensure complete

immunity to electromagnetic interference, ground loops, and signal degradation, providing reliable performance

in electrically noisy environments. The dual RS485 channels facilitate comprehensive remote device control for

cameras, PTZ systems, and other broadcast equipment requiring bidirectional communication.

This high-performance converter finds ideal application in 4K broadcast studios, live event production, sports

broadcasting, and high-resolution surveillance systems where uncompromised video quality and reliable data

transmission are essential. The integrated Gigabit Ethernet channel supports network connectivity for device

management, IP video streaming, and data transfer, while the fiber optic transmission ensures secure, interference-

free operation over extended distances. By consolidating multiple signal types through a single fiber connection,

this solution significantly reduces infrastructure complexity while providing the bandwidth necessary for next-

generation video production, establishing new standards for ultra-high-definition signal transmission in

professional broadcast applications.

Key Features Bullets

• Multi-Channel Embedded Audio
  Each 12G-SDI channel incorporates 8-channel embedded audio for comprehensive audio-video transmission

• Advanced Signal Integrity Protection
  Automatic cable equalization ensures optimal signal quality across all supported data rates

• Ultra HD Video Standard Compliance
  Supports ST-2082-1 (12G), ST-2081-1 (6G), ST-424 (3G), ST-292 (HD) and ST-259 (SD) standards

• Precision Signal Reclocking Technology
  Integrated reclocker synchronizes to SMPTE rates from 11.88Gbps to 270Mbps with precise timing recovery

• Professional Camera System Compatibility
  Direct integration with 12G/6G/3G-SDI camera systems for seamless ultra HD production workflows

• Extended Distance Transmission
  Long-range transmission capability up to 80km for large-scale deployment requirements

• Bidirectional Control Communication
  Dual-channel backward RS485 support for remote device control and monitoring

• High-Speed Network Connectivity
  1-channel 10/100/1000M Ethernet interface for data transmission and network management

• Broadcast-Grade Video Quality
  Full digital uncompressed transmission maintaining pristine 4K*2K (3840×2160@60Hz) quality

• Advanced Optical Technology
  Superior optical dynamic range with WDM/CWDM/DWDM techniques, requiring no manual adjustment
