Product Details
Place of Origin: China
Brand Name: E-link
Certification: ROHS,FCC,CE
Model Number: LNK-1612P-SFP
Payment & Shipping Terms
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: PoE Ethernet Switch Standard Export Package
Delivery Time: 5-15 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram,Paypal
Supply Ability: 500pcs/month
Keyword: |
PoE Ethernet Switch |
RJ45 Port: |
16*10/100M PoE Ports |
PoE Standard: |
IEEE802.3af /IEEE802.3at |
Bandwidth: |
9.2Gbps |
Power Budget: |
200W |
Weight: |
2Kg |
Keyword: |
PoE Ethernet Switch |
RJ45 Port: |
16*10/100M PoE Ports |
PoE Standard: |
IEEE802.3af /IEEE802.3at |
Bandwidth: |
9.2Gbps |
Power Budget: |
200W |
Weight: |
2Kg |
PoE Ethernet Switch 16 Port PoE Rack Mount SFP Ethernet Switch
PoE Ethernet Switch Advantages
► 16*10/100M PoE Ports + 2*Gigabit Ethernet Uplink Ports + 1* Gigabit SFP Uplink Port
► Support IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af/at, store and forward
► Compatible with IEEE802.3at (30W) and IEEE802.3af (15.4w)
► Ethernet port supports 10/100M adaptive and POE functions
► Flow control mode: full-duplex adopts IEEE 802.3x standard, half-duplex adopts Back pressure standard
► Support port auto flip (Auto MDI/MDIX)
► All ports support wire-speed switching
► Automatically supplied to adaptive devices
► Panel indicator monitoring status and help failure analysis
► Support VLAN Mode and Extend 250 meters Mode
► Support 1U Rack Mount
Technical Indexes
| Model | LNK-1612P-SFP Series | |||||||||
| Port | 16*10/100M PoE Ports + 2*Gigabit Ethernet Uplink Ports + 1*Gigabit SFP Uplink Port | |||||||||
| Network protocol | Support IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3z | |||||||||
| POE parameter | PoE standard: IEEE802.3af /IEEE802.3at | |||||||||
|
Each port power:15.4 W (IEEE 802.3af) Each port power:30 W (IEEE 802.3at) |
||||||||||
| PoE compatibility:IEEE 802.3af/at adaptive | ||||||||||
| POE output voltage: DC48~55V | ||||||||||
| POE power pin:1/2+; 3/6- | ||||||||||
| Network media |
10Base-T: Cat3 or later UTP/STP(≤100m) 10Base-T: Cat6 or later UTP/STP(≤250m) 100Base-TX: Cat5 or later UTP/STP(≤100m) 1000BASE-TX: Cat5 or more UTP (≤100m) |
|||||||||
| Optical (SFP) |
Multimode Fiber: 850nm, 1310nm, Transmission Distance: 550m/2Km (depending on SFP module) Single-Mode Fiber: 1310nm, 1550nm, Transmission Distance: 20/40/60/80/100/120km (depending on SFP module) |
|||||||||
| Performance |
Bandwidth: 9.2Gbps (non-blocking) Packet forwarding rate: 6.8Mpps Packet Buffer Memory: 1M MAC address table: 2K |
|||||||||
| Forwarding mode | Store-and-forward | |||||||||
| Power supply | Power input: AC100-240V 50/60Hz, Output: 52V3.8A | |||||||||
| Power Budget | 200W | |||||||||
| LED indicator |
1. |
|||||||||
| Working environment |
Working temperature:-20℃ to 55℃ Storage temperature:-40℃ to 80℃ Working humidity:10% to 90%RH no condensing Storage humidity:5% to 90%RH no condensing |
|||||||||
| Certification | CE Mark, commercial; CE/LVD EN60950, RoHS, FCC | |||||||||
| Radiation | CE mark, commercial; FCC Part 15 Class B; VCCI Class B; EN 55022 (CISPR 22), Class B | |||||||||
| Physical structure |
Product Dimension (L*W*H): 320mm*210mm*46mm Package Dimension (L*W*H): 370mm*275mm*85mm N.W: 1.8KG G.W: 2.3KG |
|||||||||
| Packaging list |
1. Ethernet Switch:1 unit 2. User Guide:1 unit 3. Warranty Card:1 unit 4. Power Cord:1unit 5. 1U Rack Mount: 1 pair |
|||||||||
| MTBF | 100000 hours | |||||||||
| Warranty | 2 years |
Overview
The LNK-1612P-SFP PoE Switch with 16 Port 10/100M PoE + 2 Port Gigabit Ethernet Uplink + 1 Port Gigabit SFP Uplink Port, it’s using high-quality high-speed network IC and the most stable POE chip, POE port meets 802.3af / 802.3at standard, this series of PoE Switch can be 10/100M Ethernet The network provides a seamless connection, and the PoE power port can automatically detect and power the powered devices that comply with the IEEE802.3af / IEEE802.3at standards. The non-POE device intelligently detects no power and only transmits data.
PoE (Power over Ethernet) refers to the technology of providing dc Power supply to some IP-based terminals (such as IP telephone, wireless access AP, network camera, etc.) while transmitting data signals. These devices receiving dc Power supply are called receiving devices.
With simple and convenient installation and maintenance methods and rich business features, it helps users to build a safe and reliable high-performance network. It is mainly located in the core or convergence layer of user networks such as industrial parks, buildings, factories and mines, government agencies, and residential broadband; it can be widely used in Ethernet access scenarios such as small and medium-sized enterprises, Internet cafes, hotels, and schools.
Ordering Information
| Model | Description |
| LNK-1612P-SFP | 16*10/100M PoE Ports + 2*Gigabit Ethernet Uplink Ports + 1*Gigabit SFP Uplink Port, support PoE power supply function, compatible with both IEEE802.3af / IEEE802.3at standard. PoE Power Output: 15.4W / 30W each port. Total power budget 200Watts. 1U Rack Mount installation |
