8-Port PoE Injector

Product Details

Place of Origin: China

Brand Name: E-link

Certification: ROHS,FCC,CE

Model Number: LNK-POE208AT

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Negotiation

Packaging Details: PoE Injector Adapter Standard Export Package

Delivery Time: 5-12 working days

Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal

Supply Ability: 1000 pcs/month

Get Best Price
Contact Now
Specifications
Highlight:
Keyword:
PoE Power Supply
Input Power:
90-240V AC ,50-60Hz
Weight:
1.5Kg
LED Display:
YES
Keyword:
PoE Power Supply
Input Power:
90-240V AC ,50-60Hz
Weight:
1.5Kg
LED Display:
YES
Description
8-Port PoE Injector

8-Port PoE Injector

PoE Adapter Advantages

► Supply power to HD network surveillance cameras with Cat5e (PoE)

► 16x 10/100M RJ45 ports; 1x AC input port; 8x PoE Ports

► AC input: 90V~264V

► Compatible with IEEE 802.3af standard(15.4W) , IEEE 802.3at standard(25.4W)

► Coming with the Ethernet network port and PoE output port

► Can supply power with the spare line pair(4/5 (+), 7/8 (-) method or the data line pair 1/2(+), 3/6(-) method

► No fan, natural heat dissipation, small, quiet design, suitable for desktop or wall

Technical Indexes

Parameter Specifications
Features

Conforms to IEEE802.3af standard RJ-45

Conforms to IEEE802.3af standard RJ-45

Data Input Interface 8*RJ-45 10/100Base-TX/

Data Input Interface 8*RJ-45 10/100/1000Base-TX

Output Port Power Cable Included
Data Rate

10/100Mbps

10/100/1000Mbps

Input Power 90-240V AC ,50-60Hz
Output Power

8*15.4W Max IEEE802.3af

8*30W Max IEEE802.3at

Wiring Data provide over pairs 1/2(+) and 3/6(-)
Power over spare pairs 4/5(+) and 7/8(-)
LED Display YES
Operating Temperature 0 to +40°C,
Humidity Max. 95% RH(non-condensing)
Dimension 280X186X44(H×D×W)
Weight 1.5KG



Overview

These 8-Port PoE injectors provide a simple, economical, high-performance and intelligent way for Ethernet PoE power supply and data communication. It’s ideal choice for those who need the superior quality project because of its simple use, easy to install, superior performance and cost-effective. They can supply power to HD webcam through Cat5 Ethernet cable, in order that make it more flexible for the places difficult to connect to power supply, and provide with more efficient solutions.



8-Port PoE Injector 0

Ordering Information



Model Decription
LNK-POE208 8-port PoE Adapter, 10/100Mbps, IEEE 802.3af 15.4W
LNK-POE208AT 8-port PoE Adapter, 10/100Mbps, IEEE 802.3at 30W
LNK-POE308 8-port PoE Adapter, 10/100/1000Mbps, IEEE 802.3af 15.4W
LNK-POE308AT 8-port PoE Adapter, 10/100/1000Mbps, IEEE 802.3at 30W
