2-Port 10/100Mbps IEEE802.3at PoE Injector Adapter

Product Details

Place of Origin: China

Brand Name: E-link

Certification: CE,FCC,RoHs

Model Number: LNK-POE202AT

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: negotiated

Packaging Details: standard export package

Delivery Time: 7days

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 5000pcs per month

Get Best Price
Contact Now
Specifications
Highlight:

poe injector 802.3 at

,

poe 802.3 af injector

,

poe adapter 802.3 at

Data Rate:
10/100Mbps
Dimension:
90 X 45 X 28mm
Humidity:
5% - 90% RH
Input Voltage:
100-240V AC
Operating Temperature:
0℃ - 40℃
Output Current:
0.625A
Output Power:
30W
Output Voltage:
48V DC
Product Name:
PoE Injector Adapter
Storage Temperature:
-20℃ - 85℃
Warranty:
2 Years
Weight:
200g
Data Rate:
10/100Mbps
Dimension:
90 X 45 X 28mm
Humidity:
5% - 90% RH
Input Voltage:
100-240V AC
Operating Temperature:
0℃ - 40℃
Output Current:
0.625A
Output Power:
30W
Output Voltage:
48V DC
Product Name:
PoE Injector Adapter
Storage Temperature:
-20℃ - 85℃
Warranty:
2 Years
Weight:
200g
Description
2-Port 10/100Mbps IEEE802.3at PoE Injector Adapter

2-Port POE Adapter Injector

2-Port POE Adapter Injector Advantages

  • ► Up to 15.4W/25.5W of PoE Power

    ► Fully IEEE802.3af/IEEE802.3at compliant

    ► Supports 10/100M or 10/100/1000M LAN environment

    ► Plug & Play

    ► No configuration required

    ► Reduced Installation cost

    ► Safe and Reliable Power to WLAN Access Points

    ► Automatic Detection and Protection of Non–standard Ethernet Terminals

2-Port POE Adapter Injector Technical Indexes



Parameter Specifications
Features

• Conforms to IEEE802.3af standard RJ-45

• Conforms to IEEE802.3af standard RJ-45

• Data Input Interface RJ-45 10/100Base-TX/

• Data Input Interface RJ-45 10/100/1000Base-TX

• Output Port Power Cable Included
Data Rate

10/100Mbps

10/100/1000Mbps

Output Power

15.4W Max IEEE802.3af

30W Max IEEE802.3at

Wiring Data provide over pairs 1/2(+) and 3/6(-)
• Power over spare pairs 4/5(+) and 7/8(-)
Output type

Single outputa

2*RJ45 connector ---POE

2*RJ45 connector ----LAN

LED Display YES
Operating Temperature 0 to +40°C,
Humidity Max. 95% RH(non-condensing)
Dimension 170*98*42mm (H×D×W)
Weight 250g

2-Port POE Adapter Injector Application

2-Port 10/100Mbps IEEE802.3at PoE Injector Adapter 0

2-Port POE Adapter Injector Ordering Information

Model Decription
LNK-POE202AT 2-Port PoE Adapter, 10/100Mbps, IEEE 802.3at 30W
