Industrial 1000M Multimode to Single Mode Fiber Media Converter

Name: Industrial 1000M Multimode to Single Mode Fiber Media Converter
Brand: E-link China Technology Co.,LTD
SKU: LNK-IMC1010
Price: 64.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: E-link

Certification: CE

Model Number: LNK-IMC1010

Document: E-link 100M Industrial MMF ....0.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: negotiation

Packaging Details: Industrial PoE Switch Standard Carton Packaging

Delivery Time: 7-10 working days

Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal

Supply Ability: 100000PCS/Month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Dimensions:	136mm×52mm×105mm (H×W×D)	Installation:	35mm DIN-Rail, Wall Mounting.
Weight:	800g	Operating Temperature::	-40℃ To 85℃
Transmission Distance:	MM 2Km，SM 20Km.

Dimensions:	136mm×52mm×105mm (H×W×D)
Installation:	35mm DIN-Rail, Wall Mounting.
Weight:	800g
Operating Temperature::	-40℃ To 85℃
Transmission Distance:	MM 2Km，SM 20Km.

Description

Industrial 1000M Multimode to Single Mode Fiber Media Converter

Product Advantages

► Supporting IEEE802.3z 1000Base-FX standards

► Supporting full-duplex and half-duplex and its auto-sensed

► Supporting conversion between 850nm/1310nm multi-mode fibers and 1310nm/1550nm single mode fibers

► Supporting direct and transparent transmission of packets at different lengths

► Supporting the transmission of extra-long VLAN packets

► Supporting Quality of Service (QoS) and ensuring the transmission of VoIP packets;

► Low power consumption, low heat, reliable and stable performance, and long lifetime;

Technical Indexes

Optical interface
Wave Lenghth	850nm, 1310 nm, 1550nm
Fiber type:	Multimode: 50/125um, 62.5/125um, 100/140um; Single Mode: 8.3/125um, 9/125um, 10/125um
Transmission Distance	MM 2Km,SM 20Km.
Fiber interface type	ST
Optic fiber module	duplex or Bi-Di
Data rate	100M
Relay
Contact rating:	DC30V@1A Max
Alarm	Fiber link fault and No voltage input
Screw Terminal	5-pin Pluggable
Power
Input Voltage:	24VDC(9VDC~30VDC)
Screw Terminal	5-pin Pluggable
dual power backup	Support
Consumption:	24VDC@60mA
Mechanical
Dimensions:	136mm×52mm×105mm (H×W×D)
Casing:	IP30 protection, Metal case
Installation:	35mm DIN-Rail, Wall Mounting.
Weight :	800g
Environmental
Operating Temperature:	-40℃ to 85℃

Overview

LNK-IMC2010 series industrial single-/multi-mode converters are applied in 1000Mbps Gigabit Ethernet Network which is wired with both single mode fibers and multi-mode fibers. The LNK-IMC2010 series is designed for use in various optical field bus networks. Feature with data rate up to 100M, 35mm DIN rail mounting, redundancy power input(9V~30VDC), relay output alarm.

Application

Industrial 1000M Multimode to Single Mode Fiber Media Converter 0

Ordering Information

Model	Description
LNK-IMC1010	Industrial 100M Multimode to Single Mode Fiber Media Converter
Mounting Options	► Default DIN-Rail Bracket installed.
Power Options	►24VDC Power Supply. Open Wire for Terminal Block
Power Options	► Power Supply is to be purchased separately.
