1080P DVI-D Fiber Optic Extender

Product Details

Place of Origin: China

Brand Name: E-link

Certification: CE

Model Number: LNK-DVI-106

Document: E-link DVI Fiber Optic Exte....0.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: negotiation

Packaging Details: Industrial PoE Switch Standard Carton Packaging

Delivery Time: 7-10 working days

Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal

Supply Ability: 100000PCS/Month

Get Best Price
Contact Now
Specifications
Highlight:
Operating Temperature::
-5℃ ~ +70℃
Dimensions (LxWxH):
94.5*73*26mm
Power Dissipation:
MAX 5W
The Warranty:
1 Year Free Warranty
Operating Temperature::
-5℃ ~ +70℃
Dimensions (LxWxH):
94.5*73*26mm
Power Dissipation:
MAX 5W
The Warranty:
1 Year Free Warranty
Description
1080P DVI-D Fiber Optic Extender

1080P DVI-D Fiber Optic Extender

Product Advantages

► Transmits DVI video signals up to 2km-10km over one fiber optic cable;

► Support video resolution up to 1920*1200@60Hz;

► Support copy EDID, can match many kind display device;

► Compliance with DVI 1.0 and HDCP 1.2 standard;

► High compatibility, can auto-match source and display device;

► Built-in automatic adjustment system, make the image smooth, clear and stable;

► Built-in ESD protection system;

► Simple to install, plug and play;



Technical Indexes

Parameter

Description

Video

Standards

DVI 1.0; HDCP 1.2



Maximum pixel clock

165MHz



Maximum data rate

6.75Gbps



Resolution range

Up to 1920X1200@60Hz



Connector

DVI-D



Impedance

100Ω

Optical fiber

Interface

SFP model – LC connector



Fiber type

Single-mode



Wavelength

Single-mode 1310nm(optional)



Interface bandwidth

10Gbps



Transmission distance

Single-mode fiber: standard 2kmmaximum 10km

Other

Power supply

The power adapter: DC 5V/2A



Power dissipation

MAX 5W



Temperature

Operating: -5 ~ +70



Humidity

Operating: 5% ~ 90%



Dimension

94.5*73*26mm



The warranty

1 year free warranty


Overview

The LNK-DVI-106 Fiber optic extender provides extension of DVI signals long distances over one fiber optic cable, it supports high resolution up to 1080P, EDID copy function. The extender can use for a wide range of applications requiring long distance transmission of high resolution with high quality by its good stability and powerful security.


Application

1080P DVI-D Fiber Optic Extender 0


Ordering Information

Model

Description

LNK-DVI-106

DVI-D to Fiber Converter: DVI-D Optical fiber transmission without compression /DVI - D, Multi-mode Fiber, 350 meters, LC(SFP), including 1 transmitter & 1 receiver, used by pairs

LNK-DVI-S106-10

DVI-D to Fiber Converter: DVI-D Optical fiber transmission without compression /DVI - D, Single Mode, Single Fiber, 10KM, LC(SFP), including 1 Transmitter & 1 Receiver, used by pairs
