4x2.5Gbps RJ45 Ports + 2 x10G SFP+ Fiber Ports Ethernet Switch

Name: 4x2.5Gbps RJ45 Ports + 2 x10G SFP+ Fiber Ports Ethernet Switch
Brand: E-link China Technology Co.,LTD
SKU: LNK-2.5G-204
Price: 293.90 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: E-link

Certification: CE, RoHS and FCC

Model Number: LNK-2.5G-204

Document: E-link LNK-2.5G-204 Etherne....0.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: $29.9-559

Packaging Details: Industrial PoE Switch Standard Carton Packaging

Delivery Time: 7-10 working days

Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal

Supply Ability: 100000PCS/Month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                              2.5Gbps RJ45 Ports Ethernet Switch, 10G SFP+ Fiber Ports Ethernet Switch


Operating Temperature::	-10℃ To 55℃	Power Consumption:	<3W
Weight:	0.3KG	Dimensions (W X D X H):	133 X 67 X 33mm

Operating Temperature::	-10℃ To 55℃
Power Consumption:	<3W
Weight:	0.3KG
Dimensions (W X D X H):	133 X 67 X 33mm

Description

4x2.5Gbps RJ45 Ports + 2 x10G SFP+ Fiber Ports Ethernet Switch

Product Advantages

· 4 x 2.5Gbps RJ45 Ports

· 2 x 10G SFP+ Fiber Ports

Overview

LNK-2.5G-204 Series Ethernet Switch provides 4 x 2.5G ports and 2 x 10Gigabit SFP+ optical ports, which can directly enjoy 2.5G high-speed transmission when connected with various 2.5G devices. It adopts the store-and-forward mechanism and integrates high-capacity cache internally, effectively reducing the data forwarding delay, and all ports can realize non-blocking line-speed forwarding.

Technical Indexes

Standards	IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3bz
Ethernet Port	Connector: RJ45 Data rate: 100M/1G/2.5G Cable: CAT6 or higher Distance: ≤100 meter
Fiber Port	Connector: SFP+ Data rate: 10G Wavelength: 850nm/1310nm/1490nm/1550nm Fiber type: Single Mode 9/125μm, Multi Mode 50/125μm,62.5/125μm Distance: 550m ~ 100km
Backplane bandwidth	60Gbps
Forwarding method	10Base-tx: 14880pps/port. 100BASE-tx:148800pps/port 1000BASE-tx:1488000pps/port 10000BASE-tx:14880000pps/port
MAC address table	4K
Port function	power supply priority mechanism, fast and forwarding, MAC automatic learning and aging IEEE802.3X Full Duplex Flow Control and Backpressure Half Duplex Flow Control
Packet forwarding rate	44.64Mpps
Power	12V DC
Power consumption	0.3W ~ 1.8W
Operation Temperature	-10℃ to 55℃
Storage Temperature	-40℃ to 85℃
Relative Humidity	10% to 90% (non-condensation)
Size	133 x 67 x 33mm
Weight	0.3KG
Material	Metal

Ordering Information

Model	Description
LNK-2.5G-204	4x2.5Gbps RJ45 Ports + 2 x10G SFP+ Fiber Ports Ethernet Switch
