Wall Mount Active POE Injector

Name: Wall Mount Active POE Injector
Brand: E-link China Technology Co.,LTD
SKU: LNK-POE200W
Price: 57.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: E-link

Certification: CE, FCC

Model Number: LNK-POE200W

Document: E-link Wall Mount Active Po....0.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: negotiation

Packaging Details: Industrial PoE Switch Standard Carton Packaging

Delivery Time: 7-10 working days

Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal

Supply Ability: 100000PCS/Month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                  Wall Mount Active PoE Injector, Wall Mount Active POE Injector, Active POE Injector


Operating Temperature::	0 To +40°C,	Size (LxWxH)::	100×48×32mm
Case:	Metal Case	Weight:	120g
Humidity:	Max. 95% RH(non-condensing)

Operating Temperature::	0 To +40°C,
Size (LxWxH)::	100×48×32mm
Case:	Metal Case
Weight:	120g
Humidity:	Max. 95% RH(non-condensing)

Description

Wall Mount Active POE Injector

95W SFP PoE Injector

Product Advantages

· Compact wall mount design

· Up to 15.4W/30W of PoE Power

· Fully IEEE802.3af/IEEE802.3at compliant

· No additional power cables required

· Built in protection circuits

· Supports 10/100M or 10/100/1000M LAN environment

· Plug & Play

· No configuration required

· Reduced Installation cost

· Safe and Reliable Power to WLAN Access Points

· Automatic Detection and Protection of Non–standard Ethernet Terminals

Overview

LNK-POE200W/LNK-POE300W wall mount active PoE injector is completely self-contained, a separate power supply and injector is not required. Compliant with IEEE802.3 af/at Ethernet power supply standard, it can be plugged directly into a wall electrical outlet, eliminating the need for additional power cables. The compact size makes it ideal for crowded equipment enclosures.

Technical Indexes

Parameter	Specifications
Features	• Conforms to IEEE802.3af standard RJ-45 • Conforms to IEEE802.3af standard RJ-45
Features	• Data Input Interface RJ-45 10/100Base-TX/ • Data Input Interface RJ-45 10/100/1000Base-TX
Data Rate	10/100Mbps 10/100/1000Mbps
Input Power	90-240V AC ,50-60Hz
Output Power	15.4W Max IEEE802.3af 30W Max IEEE802.3at
Wiring	• Data provide over pairs 1/2(+) and 3/6(-)
Wiring	• Power over spare pairs 4/5(+) and 7/8(-)
LED Display	YES
Operating Temperature	0 to +40°C,
Humidity	Max. 95% RH(non-condensing)
Dimension (LxWxH)	100×48×32mm
Weight	120g

Ordering Information

Model	Decription
LNK-POE200W	Wall Mount PoE Injector, 10/100Mbps, IEEE 802.3af 15.4W
LNK-POE200WT	Wall Mount PoE Injector, 10/100Mbps, IEEE 802.3at 30W
LNK-POE300W	Wall Mount PoE Injector, 10/100/1000Mbps, IEEE 802.3af 15.4W
LNK-POE300WT	Wall Mount PoE Injector, 10/100/1000Mbps, IEEE 802.3at 30W
