Media Converter 10 100M Fast Ethernet
, SFP Slot 10 100M Fast Ethernet
Media Converter 10 / 100M Fast Ethernet(with External Power Supply) SFP Slot
10/100M Fast Ethernet Media Converter (with External Power Supply) SFP Slot
Model : LNK-1100WSFP
Overview
The 10/100M Fast Ethernet Media Converter (with External Power Supply) SFP Slot (model:
LNK-1100WSFP) is a high-performance network conversion device designed to bridge UTP
copper cabling and fiber SFP (Small Form-Factor Pluggable) transceivers. As a 10/100M Fast
Ethernet Media Converter (with External Power Supply) SFP Slot, it strictly complies with
IEEE802.3, IEEE802.3u, and IEEE802.3x standards, ensuring seamless integration into
diverse fast Ethernet network infrastructures.
This 10/100M Fast Ethernet Media Converter (with External Power Supply) SFP Slot
supports two key media network connections: 10Base-T/100Base-TX (copper) and 100
Base-FX (fiber). It efficiently inter-converts electrical signals from 10Base-T/100Base-TX
twisted pairs with optical signals from 100Base-FX, overcoming the 100m distance limit of
copper cables by extending transmission up to 120km via fiber optic cables, greatly
expanding the reach of fast Ethernet networks.
A notable advantage of this 10/100M Fast Ethernet Media Converter (with External Power
Supply) SFP Slot is its dedicated SFP slot, which enables flexible compatibility with various
SFP transceivers, adapting to different fiber types and transmission needs. Equipped with
an external power supply, it ensures stable operation in industrial or high-demand environments
where reliable power is essential. This blend of flexibility and dependability makes it an
ideal solution for extending 10/100M fast Ethernet networks over long distances.
Features
► Supporting inter-conversion between adaptive 10Base-T/100Base-TX with 100Base-FX
► Use Port 10/100Base-TX (RJ45), 100Base-FX (SFP slot)
► Supporting full-duplex and half-duplex and its auto-sensed
► Supporting auto-sense of MDI/MDI-X, facilitating system commissioning and installation
► Supporting the transmission of extra-long VLAN packets
► Supporting Quality of Service (QoS) and ensuring the transmission of VoIP packets;
Technical Indexes
| Parameter |
Specifications |
| Access mode |
10/100Mbps Fast Ethernet |
| Standard |
IEEE802.3 10Base-T Ethernet, IEEE802.3u,100Base-TX/FX Fast Ethernet, IEEE802.3x Flow control |
| Wavelength |
850nm/1310nm/1550nm |
| Transmission distance |
multi-mode Dual-fiber: 2KM |
| single mode Dual-fiber: 20/40/60/80 Km |
| single mode Single fiber: 20/40/60/80 Km |
| Category-5 twisted pairs: 100m |
| Port |
One RJ45 port: for connecting with STP/UTP category-5 twisted pairs |
| One optical port: SFP 3.3V |
| Conversion means |
Media conversion |
| BER |
<10-9 |
| MTBF |
100,000 hours |
| LED indicator |
POWR (power supply); FX LINK/ACT (optical link action); FDX (FX full duplex), TX LINK/ACT (TP cable link/action); TX 100 (TP cable rate 100M), FX100(fiber cable rate 100M) |
| Power supply |
External Power: AC90~264V/DC100~380V input, 5V1A output |
| Power consumption |
5W |
| Operating temperature |
-10~55ºC |
| Operating humidity |
5%~90% |
| Maintaining temperature |
-40~70ºC |
| Maintaining humidity |
5% ~ 90% non-condensing |
Ordering Information
| Model |
Description |
| LNK-1100WSFP |
10/100Base-T to 100Base-F, SFP slot, excl. SFP module, standalone, external power adaptor |
